CRPO-98:UPGRADE AM CRUDE PLATFORMS ZULUF PACKAGE-1 (ZTP-7)

Location: SAUDI ARABIA

Client: SAUDI ARAMCO, KSA

Contractor: L&T ENERGY HYDROCARBON(LTEH, INDIA)

Domain: OFFSHORE OIL & GAS EPC

Standards: SAES,SAMSS, HCIS SEC DIRECTIVES, SAEP,SABP,SAIP,FORM-175 etc.

Project Description: Project consists of Installation of Five(5) Wellhead Platform upgrades and One(1) Tie-in Platform upgrade at Zuluf Field in Arabian Gulf.
Our scope includes detailed engineering & design for security network and process automation network, comprising analog telephone system, RTU communication, Fibre optic networks, security cctv system, UHF tetra-radio system, VHF marine radio system and VHF aviation(ground-to-air) radio system

PANIPAT REFINERY EXPANSION (P-25)

Location: INDIA

Client: INDIAN OIL CORPORATION LIMITED, INDIA

PMC: ENGINEERS INDIA LIMITED(EIL)

Contractor: L&T ENERGY HYDROCARBON(LTEH), INDIA

Domain: OIL & GAS REFINERY EPC

Standards: EIL STANDARDS,IS/IEC,OSHA,ANSI/ISA,API,ASME,BS/EN,ISO,NACE, NEC,NEMA,NFPA,

Project Description: Project consists of Residue Hydrocrakcer Unit(RHCU) comprises of four units i.e. Unit-401: Reactor Section & Utilities, Unit-402:Fractionation Section, Unit-403:Gas Plant Section and Unit-404: Catalyst Handling Section.
We have successfully completed Detailed Engineering Vendor Documentation Review related to Instrumentation & Control for Rotary & Static Mechanical Packages such as HP Membrane Unit, Pressure Swing Adsoprion(PSA) Unit, Catalyst Transport & Dust Control, Chemical Injection Unit, Ebullating Pumps, API Centrifugal Pumps, Reciprocating Compressor Package, Reciprocating Pumps, HPRT & Feed Pumps, Air Fin-Fan Cooler, Vacuum Package, HVAC System, Clean Agent/Gas Supression System

EPC FOR INSTALLATION OF PWT AND HCU

Location: REPUBLIC OF IRAQ

Client: GAZPROM Neft Badra B.V., RUSSIA

Contractor: Khaerat MSK Al-Iraq Co. Ltd., IRAQ

Engineering: OZONE PLANT DESIGN SERVICES PVT. LTD., INDIA

Domain: OIL & GAS PROCESSING FACILITY

Standards: ITU, IEC, ISO, BSI, EN, ANSI, TRA, EIA/TIA, IEEE, NFPA

Project Description: Produced Water Treatment Train-A, B & C and Horizontal Combustion Unit Packages at Badra Oil Field, Republic of Iraq.
We have successfully completed Detailed Engineering & Design of Field Instrumentation and Valves, DCS System, ESD System, F&G System, Process Automation Network, Process, & ESD Network, Fire & Gas Detectors, CCTV System, PAGA System, Fiber Optic Network(inside plant), Telephone System.

Ghorasal Polash Urea Fertilizer Project(GPUFP)

Location: BANGLADESH

Client: BANGLADESH CHEMICALS INDUSTRIES CORPORATION

Contractor: MITSUBISHI HEAVY INDUSTRIES LTD., INDIA

Domain: PETROCHEMICALS

Standards: IEL, ISO, Chinese National Standard(GB), IEEE, NEC, NEMA, NFPA, ANSI, JAPAN INDUSTRIAL STANDARDS(JIS, JEC, JEM), NACE, ICAO, UL

Project Description: Successful completion of Detailed Engineering & Design of Data Network and IP Telephony System, Public address & General Alarm System, Outdoor and Indoor Speaker Coverage Layouts, VHF Radio Communication System, Fire Alarm Control Panel(FACP)

HALLIBURTON MULTI-CHEM BATCH PLANT PROJECT

Location: SAUDI ARABIA, KSA

Client: HALLIBURTON ENERGY SERVICES INC., KSA

Contractor: Flour Daniel India Private Limited

TSI: SENDAN INTERNATIONAL COMPANY LIMITED, KSA

Domain: PETROCHEMICALS

Standards: HCIS SEC DIRECTIVES, ANSI/TIA, EIA/TIA, IEEE, IEC, ISO/IEC, BICSI TEDMM, ETSI EN, ITU-T

Project Description: Project consists of Telecom Systems at Halliburton Multi-Chem Batch Plant located on the Plaschem Park in Al-Jubail-2, Kingdom of Saudi Arabia.
Successfully executed Vendor Engineering & Design of Data Network and IP Telephony System, Wi-fi Heat Maps, Analogue Hotline System, PAGA & Paging System, Acoustic Coverage Study, TETRA Radio System

FIRST 250MMSCFD TRAIN OF KM500 GAS TREATMENT PLANT

Location: KURDISTAN,IRAQ

Client: PEARL PETROLEUM COMPANY LIMITED, IRAQ

Contractor: EXETERRAN CORPORATION

Domain: OIL & PROCESSING FACILITY

Standards: ANSI/NECA/BICSI, BSI PD CLC/TR, IEC, ISA, ISO

TSI: TYCO FIRE & SECURITY UAE LLC

Project Description: Successfully executed Vendor Engineering & Design of Security & Process Security CCTV System, CCTV Coverage Study(JVSG IP Video System Design Tool), PAGA & Paging System, Acoustic Coverage Study(DataKustik CadnaA Noise Prediction Software), Indoor Wi-fi System, Wi-fi Coverage Heat Maps(Acrylic Wi-fi Analyzer).

FUEL FARM COMPLEX & FUEL HYDRANT AT BAHRAIN INTERNATIONAL AIRPORT

Location: BAHRAIN

Client: BACJETFUEL, BAHRAIN

Consultant: MOTT MACDONALD

Contractor: AMANA PIPELINES CONSTRUCTION LLC

TSI: SOLUTIONS FZC UAE

Domain: OIL & GAS ONSHORE

Standards: IEEE, ANSI/TIA/EIA, ITU-T, AIR BP STANDARDS,CENELEC

Project Description: Successfully executed Vendor Engineering & Design of FO based Communication System, Network Topologies, Public Addressing & General Alarm System with Paging System, Acoustic Coverage Analysis, Operational & Security IP CCTV System, CCTV Coverage Study, Security Access Control System, Analog and IP based Telephone System and Data Network along with its interface with existing Company facilities.

EXXONMOBIL GP IMPROVEMENT WORK FOR TELECOM

Location: TEXAS, USA

Client: EXXON MOBIL CORPORATION

Contractor: LTEH-ADVENT

Domain: INFRASTRUCTURE

Standards: ANSI, EIA, IEEE, IEC, NEMA, NFPA, TIA, UL, NEC

Project Description: Our scope includes updation and rectification of ExxonMobil Global Practices(GP) which involves Offshore Fiber Optic Cabling, Microwave and Radio Data Links, Communications Tower, Computing and Telecommunication Rooms, Ship-to-Shore Link System, Offshore Safety Communications and Collision Avoidance Radar, Audio/Video Entertainment System, Very Small Aperture Terminal, Voice Service-IP Telephony, RF Cabling, Public Address/General Alarm System with Page/Party, Closed-Circuit Television, Control Systems and Equipment Management System Security Implementation, Digital Technology in Asset Management(DTAM) and Upstream Equipment Health Management(UEHM), Operations Data Surveillance System
